Manufactured from black glass-filled polypropylene, this CPP® fitting connects a ¾″ BSPP female port to larger flexible hose with a nominal internal diameter of 25 mm (1″). This step-up configuration allows a 1″ hose to connect to a ¾″ threaded port. It features a barbed hose tail and hexagonal flats for spanner installation.
Male thread: ¾″ BSPP parallel, G¾.
Thread standard: ISO 228-1.
Hose size: 25 mm (1″) nominal internal diameter.
Working pressure: 100 psi (approximately 6.9 bar) at 20°C.
Use a suitable seal for the mating BSPP connection and secure the hose with an appropriate clamp. Check material compatibility with the liquid and operating temperature. The complete assembly’s working pressure is limited by its lowest-rated component.
