¾″ Camlock Replacement Arm – 304 Stainless Steel – CPP®

CPP® replacement cam arm for compatible ¾″ female Camlock couplings. Designed to replace a worn or damaged operating arm while retaining the existing coupling body.

The cam arm is investment-cast in 304 stainless steel for strength, durability and good corrosion resistance in industrial liquid-handling applications. It is supplied complete with a fitted 304 stainless steel finger ring.

Suitable for compatible Camlock couplings manufactured to EN 14420-7 and the U.S. specification A-A-59326.

Supplied as one replacement arm, not a pair.

Specification

• Camlock size: ¾″
• Component: Replacement Camlock arm
• Quantity supplied: 1 arm
• Manufacturing process: Investment cast
• Cam arm material: 304 stainless steel
• Finger ring: Supplied fitted
• Finger ring material: 304 stainless steel
• Camlock standards: EN 14420-7 and A-A-59326
• Application: Compatible female Camlock couplings manufactured to these standard sizes
• Part number: CASI075SSS

Before fitting, confirm the arm profile, pin arrangement and coupling size match the Camlock coupling being serviced.
